Gas-tight PP drum pump
Safe and clean transfer of chemical liquids thanks to integrated gas recirculation
- Safe gas recirculation reduces emissions, protects employees and prevents unpleasant odors
- Universal adapter suitable for various container openings
- Safe shut-off system with two ball valves for hermetically sealing the conveying paths
- Chemical-resistant materials are suitable for aggressive and corrosive media
- Available for different filling container connections
Packaging unit
Piece
Detailed information
This gas-tight drum pump, which is made from chemical-resistant polypropylene (PP), has been specially developed for the safe handling of volatile, odorous or harmful liquids. This robust, hand-operated reciprocating piston pump impresses with its high delivery rate and maximum flexibility when used in containers of different depths.
These gas-tight drum pumps have been specially developed for safely handling volatile, odorous or harmful liquids. The integrated vapour recovery system, which is based on the vapour pendulum method, prevents hazardous vapours from escaping into the environment during decanting by directing them back into the original container instead.
These pumps ensure a clean, safe and efficient workflow wherever outgassing media are transferred, whether in the laboratory, production or warehouse. They are ideal for companies that prioritise emission protection, occupational safety and environmental responsibility.
Material
- Drum pump gas-tight PP
Specifications
General material
PP
Polypropylene
Further materials
PE
Polyethylene
Further materials
PVC
Polyvinyl chloride
Connection
- For openings from:
- 34 mm
- For openings up to:
- 70 mm
- Connection type:
- Variable universal stopper
Throughput
- Conveying capacity:
- 220
Limit values
- Viscosity up to:
- 500
Ø
- Pipe Ø:
- 22 mm
- Immersion tube Ø:
- 32 mm
Colouring
- Colour:
- grey/blue
Pump outlet
- Outlet hose length:
- 1.2 m
- Outlet type:
- Discharge hose
Delivery tube
- Immersion depth from:
- 40 cm
- Immersion depth up to:
- 67 cm
Further connection
- For openings from:
- 34 mm
- For openings up to:
- 70 mm
- Connection type:
- Variable universal stopper
Filling container
- For containers up to:
- approx. 220 litres
How to fill
- Drive type:
- manually operated
- Pump type:
- Reciprocating piston pump
- Special features Pumps:
- Return of gases via vapour recovery line
